China PP Spunbond Nonwoven Production Line manufacturer

Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate

Product Details:
Place of Origin: Chuzhou China
Brand Name: Chuzhou HH non-woven
Certification: CE
Model Number: smms non woven fabric production line
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: wooden case
Delivery Time: 90 - 150 days
Payment Terms: L/C, T/T
Supply Ability: For detailed talk

Detail Information

Product Name: 2.4 M Smms Non Woven Fabric Production Line Effective Width: 2400 Mm
Gsm Range: 9 - 100 G Inventer: ABB
Bearing: NSK SKF Motor: Siemes AC
Control: Siemes PLC + Touch Screen Speed: 10 - 550 M / Min
High Light:

Four Beams Non Woven Fabric Line

,

PP Non Woven Fabric Production Line

,

CE pp spunbond nonwoven production line

Product Description



SMMS Four Beam PP Spun Bond Non Woven Fabric Making Machine with Ce Certificate


Basic information about SMMS
Product name: PP spunbond non-woven production line.
Final product: SMMS PP spunbond nonwovens.
Width: 2400 mm.
Raw material: polypropylene.
Capacity: 10-18 tons/day.
Purpose: disposable nonwovens.
Color: according to customer requirements.
Provide after-sales service: engineers can repair machinery overseas.
Certificates: CE, ISO.
Machine type: non-woven cloth machine
Condition: New automatic.
Level: Automatic.
Product Description:
Use of SMMS melt-blown cloth: PP is the main raw material of melt-blown cloth, fiber diameter up to 0.5-10μm. These ultrafine fibers with unique capillary structure increase the number and surface area of fiber per unit area, so that melt-blown cloth has good air filter property, which is a better mask material. Melt-blown filter paper plays an irreplaceable role in large and medium-sized medical institutions, earthquake, flood disaster areas, SARS, avian flu and other H1N1 virus season with its strong filtering performance. Melt-blown cloth is mainly used for: A. filtration material B. medical and health material C. environmental protection material D. Clothing material e. battery diaphragm material f. wipe material

Spunmelt Composite Nonwovens Mainly Applications
Nonwoven Medical Product Surgical drapes ,Surgeon’s mask ,etc .
Nonwoven Hygiene Product Baby and adult diapers
Work protection product Protctive clothing , breathing masks
Nonwoven Filtration product Protective clothing , breathing masks



Meltblown Nonwovens Mainly Applications
Nonwoven Sanitary product Female hygiene,child and baby hygiene,Incontinence products,pads ,Absorbing pads ,Functional inserts for controlled absorption
Nonwoven Absorbents product Absorbent cloths and wiping cloths,liquids (benzene,water ,blood),Media for oil absorption
Nonwoven Filtration Product Air ,Gas,liquids(benzene,water,blood),etc.



Spunbonded Nowovens Maily Applications
Nonwoven Hygiene Product Cleaning wipes:Baby care , cosmetics ,etc.Baby and adult diapers:Top sheets , back sheets ,ears, tapes, landing zone;Female hygiene:Wings ,Top sheets
Nonwoven Medical Product Surgeon’s mask ,disposable garments ,Surgeon’s Cap,surgical drapes ,surgical sheet ,shoe covers , etc
Nonwoven packaging Product Shopping bag ,rice backaging ,tea bag ,clothes packaging, etc.
Nonwoven Furniture product Seating:sub-paneling, intermediate layers .Beds:Pocket springs, mattresses, cushions, bed covers, disposal bedding ,etc.
Nonwoven Technical product Structural,engineering:roofinsulation,sheeting ,diaphragms Agriculture :Crop forcing nonwovens,insect protection ,etc.Geotextile:Erosion protection,filtration,reinforcement,drainage,separation layers, embankment fortification etc.for streets,dikes, and farms.Agriculture:Crop forcing nonwovens,insect protection,etc. Automotive:Inner paneling,sound insulation,insulation, etc.



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 0



2400 SMMS Model

Effective Width 3200mm
Weight Range 9 - 100 g / ㎡
Out put daily 14 - 24 ton
Machine speed ≦ 450 m / min
Transformer ≈ 1600 KVA
Power Consumption 1700º - 1900 º / Ton
Machine Size 55 *23* 12 M



Major Characteristics:
1. The whole line is well-structured and easy to operate
2. The whole line highly automated
3. Control elements are of well-know make, high performance and reliable technologies
4. The whole line are controlled by PLC and operated with touch -scree.
5. The allocation of the main frame and auxiliary equipment can be special designed and configurated according to customer's requirements.







smms non woven fabric character



G/m2 17 30 60
MD N/5 cm >23 >40 >81
CD N/5 cm >11 >22 >45
MD Elongation% >30 >30 >30
CD Elongation% >30 >30 >30
Hydro-static pressure >110 >200 >300








Product application

Material PP chip Weight range 10-150 g/m2
Model

HHM-1.6SMMS/HHM-2.4SMMS

HHM-3.2SMMS/HHM-4.0SMMS/HHM-4.8SMMS

Fabric usage

Medical applicant,shopping bag , packing

Operation suit,face mask, baby diaper.etc







Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 1

Technical Parameters



Model

HHM-1.6

SMMS

HHM-2.4SMMS HHM-3.2SMMS HHM-4.0SMMS HHM-4.8SMMS
Effective width 1.6M 2.4M 3.2M 4.0M 4.8M
Weight range 10-100g/m2 10-100g/m2 10-100g/m2 10-100g/m2 10-100g/m2
Out put per day 7-12Ton 10-18Ton 14-24Ton 17-30Ton 21-36Ton
Machine speed ≦400/min ≦400/min ≦400/min ≦400/min ≦400/min
Transformer capacity ≦1500KVA ≦1600KVA ≦2200KVA ≦25000KVA ≦2630KVA
Power consumption 1400º-2000º/Ton 1400º-2000º/Ton 1400º-2000º/Ton 1400º-2000º/Ton 1400º-2000º/Ton
Machine Size(L*W*H) 45m*18m*12m 45m-22m*12m 45m*25m*12m 45m*28m*12m 45m*31m*12m



M Model

Working width Fabric Power input Consumption Annual output/Year
1600mm 15-300G/㎡ ≈600KVA 3000º-3500º/Ton 800T
2400mm 15-300G/㎡ ≈800KVA 3000º-3500º/Ton 1100T
3200mm 15-300G/㎡ ≈1000KVA 3000º-3500º/Ton 1500T



SMS Model

Working width Fabric Power input Consumption Annual output/Year
1600mm 9-100G/㎡ ≈800KVA 1300º-1600º/Ton 3200T
2400mm 9-100G/㎡ ≈1250KVA 1300º-1600º/Ton 5100T
3200mm 9-100G/㎡ ≈1600KVA 1300º-1600º/Ton 7000T
4000mm 9-100G/㎡ ≈2000KVA 1300º-1600º/Ton 8700T
4800mm 9-100G/㎡ ≈2250KVA 1300º-1600º/Ton 10500T

SMMS Model

Working width Fabric Power input Consumption Annual output/Year
1600mm 9-100G/㎡ ≈1500KVA 1700º-1900º/Ton 4000T
2400mm 9-100G/㎡ ≈1600KVA 1700º-1900º/Ton 6200T
3200mm 9-100G/㎡ ≈2200KVA 1700º-1900º/Ton 8400T
4000mm 9-100G/㎡ ≈2500KVA 1700º-1900º/Ton 10500T
4800mm 9-100G/㎡ ≈2630KVA 1700º-1900º/Ton 12700T


Parts of spunbonded nonwoven fabric production line:



Recycle extrude→Main extruder→Filter→Metering pump→Monomer suction device→spinning box( Changzhou/ENKA/KASEN spinneret )→Quenching air chamber→stretching device→Web former→Calender→Winder→Slitter



Spunbonded process and technical flow chart:



Additive(Recycling off-cut fabric)→Raw material→Melting→Filtering→Measuring→Spinning→Cooling→Stretching→Web forming→Calendering→Winding→Cutting→Final product



Parts of Melt blown nonwoven fabric production line:



Main extruder→filter→Metering pump→Air heating system→Melt blown sprayer (ENKA sprayer)→Web former→Winder→Slitter



Melt blown process and technical flow chart:



Raw material →Melting→Filtering→Measureing→Air heating→Spraying→Web forming→Winding→Cutting→Final product

Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 2

Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 3

Main parts of non woven system



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 4



The role of spinneret is to transform viscous flow of polymer melt or solution into small section with special section, and solidify through solidified medium, such as air or solidification bath. It is used for the uniform exit of the tow.





Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 5

Two cooling blower for each other pressure gauges, pressure switches, air channel transfer baffles, air oil and water filter separators, cooling fan control cabinet and so on. Two cooling fans share a control cabinet to automatically control the start and stop of the two typhoon machines. The cooling wind can be taken directly from the air or from the outlet of the fan.



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 6

Control the pressure oil temperature of oil pressure system, stabilize oil temperature and oil pressure, prolong oil use time, improve the efficiency of mechanical lubrication and reduce wear. Freeze dry air to guarantee the quality of the product.



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 7

Meltblown die head assembly

maximum temperature: 300.;

Max.output:200kg/h;

Heating zone:8tod;

Perforated length:3,350mm;

HPI:40;

1 Sets L/D=10; Number of holes:5.276;

Capillary diameter:0.3mm;

Capillary length:3,600mm;



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 8

Extrusion Machine

Aperture:90 300kg/h 1pc;

Heating System: electricity heating; Drive Motor: Siemens; Original:CHINA;



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 9



Spinning Box uses hot oil for heating and insulation in cycle with reasonable structure, attractive appearance and low power consumption. It also charaterizes that the thickness of the fiber is uniform and the feeling of monofilament is fine without brokrn and rough warp, etc.



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 10

.Auto Winder

Machin

The main function is to wrap the hot rolled fabric into a certain volume."



Slitter&Cutter

The main function for a large package of cloth cutting according to customer specifications, to meet the customer's length, width, volume weight requirements.



Precisely CNC center hold machining part beyond customer request



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 11





Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 12



Exhibition Show with customer

Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 13





Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 14





Shipment and packing



 Large parts wrapped in several turns of films, small parts boxed in a wooden crate, each
packaged is numbered and packed to easy loading/unloading and installation



Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 15





Four Beams PP Spunbond Non Woven Fabric Production Line With CE Certificate 16



FAQ



Q1: What made you choose HH?
A: HH has a team of professional engineers directly to your factory to install our spun-bonded
non-woven fabric making machine and melt-blown machine which high-speed, stable, and reliable
to help you quickly establish your own production line.

Q2: Are you a manufacturer?

A: Yes, we are a professional manufacturer of nonwoven machinery. We also had established
our own trading company to expand our foreign market business and provided our customer with
better service.

Q3: Do you accept OEM?

A: Of course we are.

Q4: How long is the warranty period?

A: We provide 1 year warranty period.

Q5: What's your packing?

A: Large parts wrapped in several turns of films, small parts boxed in a wooden crate, each
packaged is numbered and packed to easy loading/unloading and installation.

Q6: Can customers send workers to your place to study the operation of the machine?

A: Of course, you are warmly welcome.
