China PP Spunbond Nonwoven Production Line manufacturer

250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation

Product Details:
Place of Origin: Chuzhou China
Brand Name: Chuzhou HH non-woven
Certification: CE
Model Number: HH Meltblown
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: components wood box packaged , machine wrapping with PE film keep cargo safe
Delivery Time: 90 - 150 days
Payment Terms: L/C, T/T
Supply Ability: 3 line / months

Detail Information

Description: Meltblown Fabric Production Line Effective Width: 1.6 M
Transformer: 600 KVA Consumption: 250 KW / H
Gsm: 250 G Customized: Accepted
Weight: 25 Ton Type Supplyer: Manufacture
High Light:

1.6M pp nonwoven fabric machine

,

250gsm meltblown nonwoven fabric machine

,

250gsm sms non woven fabric making machine

Product Description

Ce Certified easy operation Melt Blown Non Woven Fabric Production Line





Melt blown cloth is a short polymer one-step process. It has high filtration efficiency, low resistance and softness. The network can tie and bond itself. Therefore, it is widely used in different countries. It is mainly used in China and sub filtration, including air filtration, acid filtration, food hygiene filters, industrial production dust masks. It can also be used as sanitary products, industrial cloth, insulating material, oil absorbing material, battery partition, leather imitation cloth, etc
Melt blown fabric is a kind of high-speed heat flow, which stretches the polymer melt extruded from the spray hole to form ultrafine fibers, which gather on the mesh curtain or mesh roller to become melt blown non-woven fabric

250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 0



This Line is used for the production of polypropylene nonwovens.

Polypropylene as the main raw materials, supplemented by additives

such as electrostatic additives masterbatch or color masterbatch,

It can produce polypropylene melt blown nonwovens for different purposes.



Description Melt blown machine raw material



Raw materials pp polypropylene Melting point 166℃
Spunbond pp melt index 28-45 Denier of spunbond fiber 1.8-2.5 denier
Meltblown pp melt index 1300-1800 Denier of melt blown fiber 1.6-4 microns





250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 1





Technical Parameters

Model HHM-1.6m HHM-2.4M HHM-3.2M
Effective Width 1.6 M 2.4 M 3.2 M
Weight Range 18-300 G/㎡ 18-300 G/㎡ 18-300 G/㎡
Out put day 2-3 Ton 3-4 Ton 4.5-5 Ton
Machine Speed ≦70 m/min ≦70 m/min ≦70 m/min
Power Consumption 3000º-3500º/Ton 3000º-3500º/Ton 3000º-3500º/Ton
Machine Size(L*W*H) 18M*10M*10M 18M*11M*10M 18M*13M*10M





Meltblown Making Machine Series

Model

Product Width

(mm)

GSM Range

( g / ㎡ )

Capacity

(kg /day )

Melt blown

(BFE&PFE)

HHM- 1600 1600 15 - 300 200 - 300

BFE 99+

PFE 95+

HHM - 2400 2400 300 - 400
HHM - 3200 3200 450 - 500







Meltblown non-woven fabric production line components:

Screw extruder---->filter---->metering pump---->heating system---->melt blown box (Kasen)---->netting machine---- >Rewind

 Meltblown production process flow chart:

Raw Material----> Melt Extrusion----> Filtration----> Metering----> Air Heating Compression----> Melt Blown----> Web Formation----> Winding



250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 2





Meltblown non-woven fabric production line components:





Screw extruder---->filter---->metering pump---->heating system---->melt blown box (Kasen)---->netting machine---- >Rewind





(1) Receiving networked device:

Line speed: up to 50m/min

Meltblown receiving adjustment range: 200mm

Installation form: It can be moved horizontally, which is convenient for installation, debugging and maintenance

Driving rate: 1.1KW

(2) Suction net fan:

Power: 75KW,

4. Hot air heating system

(1) Atlas air compressor

Boost pressure: 0.7MPa

Power: 120KW~200KW

(2) Air heater

Heating power: 220KW-240KW

Material of tank and pipeline: stainless steel 304

Insulation form: stainless steel seal outside the insulation layer

5. Electret system.

6. Rack platform device:

Steel structure, easy to disassemble, firm and reliable, including stairs, etc.

7. Die head heating power: about 70kw

8. Electrical control box



250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 3





250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 4







250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 5





250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 6





250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 7





250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 8





High precisely CNC center



250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 9









250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 10





Exhibition Show



250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 11



250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 12



Packing & shipping



Main machine parts will be packed with wooden cases.Electrical parts will be packed with plastic and then packed into wooden cases.For the steel structure they will be packed in bulk into containers.



250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 13





250gsm 1.6M PP Meltblown Nonwoven Fabric Machine Easy Operation 14



FAQ



1.Q : Are you a factory or trading company ?

A : We are established in 2009 , has been in onwoven industry for more than ten years .

2.Q: Do you have technical support?

A: yes , we will provide on-site installation service.

3 Q : How does your factory do regarding quality control ?

A: Quality is the most important principle . we always attach great importane to quality controlling from the very beginnging to the very end , our factory has passed CE and ISO certification .

4 Q :How long is you machine’s warrant period .

A : bascily one year warranty , long time service support .
